Lead Sheet Quality: What Are Barmarks and Why Do They Matter?

• Barmarks are linear indentation marks that appear on lead sheet produced from heavy coiled bobbins.
• They do not affect the waterproofing performance of lead sheet but can be clearly visible on a finished roof, sometimes from ground level.
• Removal is extremely difficult and is no longer considered acceptable in modern roofing practice.
• Abbey Metals manufacture from flat plate rather than bobbins, so Barmarks cannot occur.

The finish of a lead roof depends on more than the skill of the person installing it. The quality of the lead sheet itself plays a significant part. Lead that carries surface marks from the manufacturing process will show those marks on the finished roof, sometimes clearly enough to be seen from the ground. This post explains one of the most common manufacturing defects in lead sheet, what causes it, why it is so difficult to fix once it appears, and why Abbey Metals lead does not have it.

Quality Lead Sheet: Why Manufacturing Method Matters

Not all lead sheet is manufactured the same way, and the differences show up in the finished product. One of the most visible signs of a manufacturing problem in lead sheet is Barmarks. Understanding what they are, and how to avoid them, is part of specifying and sourcing quality lead.

What Is a Barmark?

A Barmark is a series of perpendicular linear indentations that run along the full length of a lead roll. The marks are spaced in line with the circumference of the roll, with the intervals between them narrowing as they approach the centre. They are not surface scratches or handling damage. They are a product of how the lead was made.

The cause is the manufacturing process. When lead sheet is produced from heavy coiled bobbins, the pressure and geometry of the coiling process leaves these marks in the material. They transfer to the sheet and remain there.

Do Barmarks Affect Performance?

In terms of waterproofing and structural performance, Barmarks are unlikely to cause problems. Lead sheet carrying Barmarks will still do its job.

The issue is visual. When lead is laid in bays on a roof, Barmarks run across the surface in a regular pattern. On a finished roof they are often clearly visible. In some cases, particularly with more pronounced marks, they are visible from ground level. For a material that forms part of the finished appearance of a building, that matters. A well-installed lead roof should look as good as it performs, and Barmarks work against that.

Can Barmarks Be Removed?

Removal is not straightforward. Historically, on lighter codes of lead, contractors would try to flap out the marks by using a strip of lead to repeatedly strike the affected area. On heavier codes, the only option was to heat the sheet and dress the marks out by hand. Both methods are time-consuming and physically demanding. In modern roofing practice, neither is considered an acceptable approach.

If Barmarks are present in the lead you have specified, the realistic options are to work with them or to source different material.

Why Abbey Metals Lead Is Barmark-Free

Abbey Metals manufactures lead sheet from flat plate, not from heavy coiled bobbins. Because Barmarks are caused by the bobbin process, they cannot occur in flat plate manufacture. Abbey Metals lead is Barmark-free as a direct result of how it is produced.

This is not a processing claim or a treatment applied after manufacture. The marks are absent because the process that creates them is absent. Every roll of lead sheet supplied by Abbey Metals is free of Barmarks across all four colour codes, Code Green, Code Yellow, Code Blue, and Code Red.

For contractors who take pride in the finish of their work, and for specifiers who need to be confident in the quality of what goes on a roof, that is worth knowing before you order.

Frequently Asked Questions

What are Barmarks in lead sheet?

Barmarks are a series of perpendicular linear indentations that run along the full length of a lead roll. They are caused by the manufacturing process when lead is produced from heavy coiled bobbins. The marks are spaced in line with the roll circumference, with the intervals narrowing towards the centre of the roll.

Do Barmarks affect the performance of lead sheet?

Barmarks are unlikely to affect the waterproofing or structural performance of lead sheet. The problem is visual. When lead is laid in bays, Barmarks can be clearly visible on the finished roof. In some cases they are pronounced enough to be seen from ground level, which undermines the overall appearance of the work.

Can Barmarks be removed from lead sheet?

Removal is extremely difficult. On lighter codes it was historically possible to flap out the marks using a strip of lead to strike the affected area repeatedly. On heavier codes, heating and dressing the sheet was the only option. Both methods are labour-intensive, slow, and are no longer considered acceptable in modern roofing practice.

Why is Abbey Metals lead Barmark-free?

Abbey Metals manufactures lead sheet from flat plate rather than heavy coiled bobbins. Because Barmarks are caused by the bobbin process, they cannot occur in flat plate manufacture. Abbey Metals lead is Barmark-free as a result of how it is made, not as a processing claim.

Abbey Metals supplies Barmark-free lead sheet across all colour codes, with a 50-year guarantee on correctly installed material. Stock is available for fast despatch, whether you need Code Green soakers, Code Yellow flashing or Code Blue flashing, or Code Red when the detail is wider, more exposed or subject to greater water loading. Contact the Abbey Metals team to discuss your requirements or place an order.
